Connecting Your WEC3 Controller to Your Home WiFi Network

Table of Contents

• Setting Up Your WEC3 Controller for WiFi Connectivity
• Verifying the WiFi Connection
• Troubleshooting Common Issues
• FAQ

Setting Up Your WEC3 Controller for WiFi Connectivity

Connecting your WEC3 controller to your home WiFi network is a straightforward process that will allow you to control your Minleon Permanent Lighting system remotely using the Pixel Dancer app. In this blog post, we’ll guide you through the necessary steps to get your WEC3 controller up and running on your home WiFi network.

Preparing Your WEC3 Controller

Before you begin, ensure that your WEC3 controller is powered on and that your mobile device has an active WiFi connection. You’ll also need to have your home WiFi network name (SSID) and password readily available.

Connecting to the WEC3 WiFi Network

The first step is to connect your mobile device to the WEC3 WiFi network. This network is typically named “WCK-[some_number]” and is broadcast directly by the WEC3 controller. Once you’ve connected to this network, you can proceed to the next step.

Configuring the WEC3 Controller in the Pixel Dancer App

Open the Pixel Dancer app on your mobile device and look for the gear icon in the top right corner. This will take you to the app’s settings menu. In the settings menu, locate the “Network Mode” option and select it.

In the Network Mode screen, you’ll see three fields that need to be filled out:

1. WiFi Name: This is the name of your home WiFi network (SSID).
2. WiFi Password: This is the password for your home WiFi network.
3. WCK Name: You can leave this as the default “WCK-[some_number]” value.

Once you’ve entered the necessary information, you can choose either “None” or “Master” in the “Mode” field, depending on whether you have a single controller or multiple controllers. Then, click the “Reboot WEC3” button to save the changes and reboot the controller.

Verifying the WiFi Connection

After the WEC3 controller has rebooted, you can check your mobile device’s WiFi settings to ensure that it has successfully connected to your home WiFi network. If the connection is successful, you should be able to close the Pixel Dancer app and reopen it to control your Minleon Permanent Lighting system using your home WiFi network.

Troubleshooting Common Issues

If you encounter any issues during the setup process, there are a few things you can try:

Constant Flashing Green Light on the WEC3 Controller

If the green light on the WEC3 controller is flashing constantly and never stops, it means that the controller was unable to connect to the WiFi network. This could be due to an incorrect WiFi name or password, or other network-related issues.

To resolve this, you’ll need to perform a hard reset of the WEC3 controller. Here’s how to do it:

1. Unplug the control box.
2. Unscrew the 4 screws holding the clear cover of the controller in place.
3. Push and hold the black button in the center of the controller while plugging in the control box again.
4. Continue holding the black button for 5 seconds after the control board has been plugged in, then release the button.
5. Wait about 30 seconds for the controller to reset.

After the reset, you can try reconnecting the WEC3 controller to your home WiFi network following the steps outlined earlier.

FAQ

Can I connect multiple WEC3 controllers to the same WiFi network?

Yes, you can connect multiple WEC3 controllers to the same WiFi network. When configuring the controllers in the Pixel Dancer app, you’ll need to set the “Mode” field to “Master” for one of the controllers and leave the others set to “None”.

What happens if I forget my WiFi password?

If you forget the WiFi password for the network you’ve connected your WEC3 controller to, you’ll need to perform a hard reset of the controller and then reconnect it to your home WiFi network using the correct password.

Can I use a 5GHz WiFi network with the WEC3 controller?

Yes, you can use a 5GHz WiFi network with the WEC3 controller. Just make sure to select the 5GHz network when connecting your mobile device to your home WiFi.

Do I need to keep the Pixel Dancer app open to control my Minleon Permanent Lighting system?

No, you don’t need to keep the Pixel Dancer app open. Once your WEC3 controller is connected to your home WiFi network, you can control your lighting system using the app even when it’s running in the background or closed.

By following the steps outlined in this blog post, you should be able to successfully connect your WEC3 controller to your home WiFi network and start controlling your Minleon Permanent Lighting system remotely using the Pixel Dancer app. If you encounter any further issues, don’t hesitate to reach out to the Minleon support team for assistance.
